Decoding Hazardous Location Sensor Markings

Hazloc certification markings can seem like Egyptian hieroglyphsAttempting to read and understand certification markings on a sensor designed for hazardous locations is a bit like learning a new language. Even for a seasoned engineered, these markings can be cryptic. So to de-mystify these markings, and help you understand what you’re getting, we’ll provide some translations for you.

Disclaimer: We will discuss CSA and FM markings on level and pressure sensors only. Most of this information is gathered from CSA International. This is openly available to anyone who wants to put in the research time, but we weren’t able to find it well organized. We provide it here to save you the time. Refer to the appropriate source for the most up-to-date information as codes can change regularly.

To kick us off, we should start by defining exactly what information is provided in a specific sensor marking. There are a really two ways of presenting information – one for North America, and one for Europe/International. In an effort to keep it simple, it’s best to think of these two standards as the division system (North America) and the zone system (International):

Division System

Zone System

Hazard Classification

Class 1,2,3

Hazard Classification

Class 1,2,3

Area Classification

Division 1,2

Area Classification

Zone 0,1,2

Gas Group

Groups A – G

Code Conformity

A (U.S.) or E (Europe)

Temperature code

T1 – T6

Explosion Protection

Ex





Protection Method

i,d,p,e,m,o,q,n





Gas Group

IIA - IIC





Temperature code

T1 – T6

For example, here are markings from the same sensor, represented using both the division system and the zone system:

Class I, Div. 2, Groups C & D, T6

Class I, Zone 2, AEx nA IIB T6 (refer to our LPU-2127 ultrasonic sensor)

You may notice a few oddities. This is why translation can be so difficult. First, the “A” declaring that the sensor conforms to U.S. code is combined with the “Ex” declaring explosion protection. This is simply how it’s done.

Second, the “n” specifying a Non-Incendive protection method has a capital “A” next to it. This is to specify non-arcing.

Unfortunately, there are a lot of quirks in certification markings. You just have to get used to it. Fortunately, most of you won’t have to worry about the really specific stuff, such as non-arcing. For those who need to know it, you can refer to code documentation from either the NEC or the IEC.

Refer to the tables below for a complete translation:



Division System

Hazard Classification

Class 1

Gas, Vapors

Area Classification

Division 2

Abnormal Conditions

Gas Group

Groups C & D

Ethylene, Propane

Temperature code

T6

Max Surface Temp 85° C



Zone System

Hazard Classification

Class 1

Gas Vapors

Area Classification

Zone 2

Abnormal Conditions

Code Conformity

A

U.S.

Protection

Ex

Explosion

Protection Method

nA

Non-Incendive/Non-Arcing

Gas Group

IIB

Ethylene

Temperature code

T6

Max Surface Temp 85° C



Every now and then, the division system is appended with additional markings such as this:

Class I, Div. 1, Groups C & D, Ex ia IIB T4 (refer to our Hammer Union Pressure Transducer)

You’ll notice the markings “Ex” for explosion protection, “ia” for intrinsic safety (2 faults), and “IIB” for ethylene gas have been thrown into the mix. Don’t worry about this, as the meanings are still the same. Just use the zone system translation to decode this.

The zone system markings for the same sensor read as follows:

Class I, Zone 0, AEx ia IIB T4

We could pour over example after example. However, to help you translate any hazardous location markings, we’ll wrap up with a list of (almost) all the markings used in the division and zone system. Enjoy! Let us know if you have any questions.



Protection Methods

Division





1

ia

Intrinsic Safety (2 faults)

1

ib

Intrinsic Safety (1 fault)

1

d

Explosionproof/Flameproof

2

n

Non-Incendive/Non-Sparking



Gas Groups

Division

Zones



A

IIC

Acetylene

B

Hydrogen

C

IIB

Ethylene

D

IIA

Propane

8

Temperature Codes

Division

Zones

Max Surface Temp (°C)

T1

T1

450

T2

T2

300

T2A

-

280

T2B

-

260

T2C

-

230

T2D

-

215

T3

T3

200

T3A

-

180

T3B

-

165

T3C

-

160

T4

T4

135

T4A

-

120

T5

T5

100

T6

T6

85
